Related Concrete Equipment -

LSY series Screw Conveyor

Type:

Screw Conveyor

Characteristic:

New conveying equipment

Model:

LSY Series

Type:	Screw Conveyor
Characteristic:	New conveying equipment
Model:	LSY Series

Product characteristics

The LSY series screw conveyor is an equipment that conveying materials with rotating spiral (screw)device in a closed housing with round cross-section. It is mainly used to conveying various kinds of powder or granular materials. And it can be used horizontally or tilting, especially suitable for conveying bulk cement from the cement silo to the mixer or to the batching machine.
The LSY series of spiral conveyor is a kind of new equipment that conveying materials with rotating spiral device in a closed housing with round cross-section. It is mainly used to conveying various kinds of powder or granular materials. And it can be used horizontally or tilting, especially suitable for conveying bulk cement from the cement bin to the mixer or to the batching machine.
1. We choose the famous brand parts for our screw conveyor;
2. If required by our clients, SICOMA and WAM brands are available also;
3. Equipped with universal joint, can be easily matched with different requirement.

Model parameters

Model	LSY160-2.5	LSY160-4.5	LSY200-6	LSY200-8(9)	LSY250-8(9)	LSY300-9(12.15)
Metric Diameter of Screw	160	160	185	185	237	305
Length of Screw Conveyor	2.5	4.5	6	8(9)	9(12.15)	9(12.15)
Rotary Speed of Main Axle	112	112	100	100	90	80
Sheave Diameter	Φ 180	Φ 180	Φ 219	Φ 219	Φ 273	Φ 325
Working Angle	≤20	≤20	≤45	≤45	≤45	≤45
Conveying Capacity	25	25	35	35	45	75
Motor Modes	Y100L2-4	Y112M-4	Y132S-4	Y132M-4	Y160L-4	Y180L-4
Power of Motor	3	4	5.5	7.5	15	18.5

mini mobile concrete batching plant

concrete trailer mixer

concrete mixer companies

ready mix concrete batching plant

The LSY series of spiral conveyor is a kind of new equipment that conveying materials with rotating spiral device in a closed housing with round cross-section. It is mainly used to conveying various kinds of powder or granular materials. And it can be used horizontally or tilting, especially suitable for conveying bulk cement from the cement bin to the mixer or to the batching machine.
